Details
General details
Operating Voltage : DC 24V
Operating Temperature : -20°C to 60°C
Dimensions : 127(W) x 150(D) x 75(H)mm
Printing head
Method : Direct line thermal dot
Print speed : Max. 200 mm/sec.
Resolution : 8 dots/mm (203dpi)
Number of dots/line : 576 dots (Default) 560 dots
Paper
Paper Width : 80 mm (Default) / 76 mm / 82.5 mm
Print Width : 72 mm (Default) / 70 mm / 80 mm
Paper Diameter : Max. 83 mm
Paper Thickness : 59~150 micrometer
Software
Character : International, English, Greek, Polish, Russian, Scandinavian, Turkish, Chinese, Korean, Japanese
Barcode : UPC-A / UPC-E / JAN13(EAN13) / JAN8(EAN8) / CODE39 / ITF / CODABAR / CODE128
Interface : USB (V2.0 FULL SPEED) and Serial (RS232C)
Auto-Cutter : Full cut and Partial cut *Command selectable
Printer Driver : EX Driver, DS Driver, Linux CUPS Driver, OPOS Driver, Library for Android
Accessories
Model Name : PS8 | Model Name : BEZ-320/330/331/332 | Model Name : BEZ-220/221/230/231 |
![]() |
![]() |
![]() |
1. Universal input voltage: 100 - 240V 2. 2 types DC output cable connector 3. Compact type AC adapter |
1. Paper width 2-inch~3-inch | |
Model Name : NPT-306 | Model Name : UPH-LA | |
![]() |
![]() |
|
1. Retraction presenter 2. Small design 3. Reasonable price 4. Fully controllable action (clamping, ejection and retraction) |
1. Universal Paper Holder 2. Compatible with NP-2411/3411, 2511/3511 series 3. A more cost effective solution due to a simplified design and less substatial structure |
Operating Temperature Min : -20°C, Max: 60°C
Dimensions : 127(W) x 150(D) x 75(H)mm
