Common characteristics of the CLP13 potentiometers :
- Protection class : IP45
- Resolution : < 0.01
- Housing : aluminium
- Standard tolerance : ±10 %
- Bearing : sleeve bearing
- Cursor current : 1 mA
- Maximal speed : 5 m/sec
- Lifetime : 10 x106 rotations
Differences between the CLP13 potentiometers :
| CLP13-13 | CLP13-25 | CLP13-50 | CLP13-100 | |
| Electrical travel | 12.7 mm | 25.4 mm | 50.8 mm | 101.6 mm |
| Ohmic value | 0.5 kΩ à 10 kΩ | 0.5 kΩ à 10 kΩ | 1 kΩ à 20 kΩ | 1 kΩ à 20 kΩ |
| Linearity | ±1 % | ±0.7 % | ±0.5 % | ±0.3 % |
| Power rating | 0.2 W | 0.4 W | 0.7 W | 1.2 W |
